Product Introduction

Conductor: fine bare copper wire, section 0.1mm2 (VDE 0295 Class6 standard)

Insulation: PVC/TPE/PE/ automotive material

Skein: double skein

Color: When the cross-sectional area is less than 0.5mm2, color separation is adopted (DIN 47100 standard).

When the cross-sectional area is greater than or equal to 0.5mm2, black cable core white digital code + yellow/green cable is used

Shielding: aluminum foil wrap + tinned wire braid

Purpose

TRVVSP cable is a flexible, twisted, shielded cable that can be used in a towing chain. The pair structure can effectively prevent crosstalk between adjacent wire pairs, and the copper mesh braided shield can also effectively prevent interference from internal and external, so that the data transmission is more secure and reliable.

Characteristic

TRVVSP cable is a flexible, twisted, shielded cable that can be used in a towing chain. The pair structure can effectively prevent crosstalk between adjacent wire pairs, and the copper mesh braided shield can also effectively prevent interference from internal and external, so that the data transmission is more secure and reliable.

Performance

Bending times: 5 million ~8 million times, more requirements please contact us

Bending radius: When the travel is less than 10 m, the bending radius is 7.5x cable diameter

When the travel is greater than 10m, the bending radius is 10x cable outer diameter

Moving speed: 3m/S~5m/S

Rated voltage: 300/300V when the cross-sectional area is less than 0.5mm

300/500V when the cross-sectional area is greater than 0.5mm
